Lauritz Knudsen AU HR MCB, 1 Pole, C Curve, 15kA, 80A, 240V | Suitable for Isolation | Protection Degree - IP 20
Images:
Image 360:
How to video:
Further offers for this product
Incl. Tax
In Stock
No sellers found for this product.
Incl. Tax
Lauritz Knudsen AU HR MCB, 1 Pole, C Curve, 15kA, 80A, 240V | Suitable for Isolation | Protection Degree - IP 20
- Description
- Specifications
- Documents
- Warranty
- Reviews
Description
About the Product
The AU HR MCB 80A SP 240V AC 15kA C Curve is a high-rated Miniature Circuit Breaker designed to provide protection against overloads & short circuits in electrical installations. It is suitable for residential, commercial, & industrial applications where high current protection & reliability are required.
With an 80A current rating & a 15kA breaking capacity, this MCB ensures effective fault interruption even under heavy fault conditions. The C Curve tripping characteristic makes it ideal for circuits with moderate inrush currents such as motors & inductive loads.
How the MCB Works
This MCB provides protection by automatic circuit interruption:
• Monitors current flow in the circuit
• Trips when overload conditions persist
• Instantly disconnects during short circuit faults
• Prevents damage to wiring, devices, & equipment
This ensures safety & reliability of the connected electrical system.
Electrical Configuration
• Rated current: 80A
• Poles: Single pole (SP)
• Rated voltage: 240V AC
• Breaking capacity: 15kA
• Tripping curve: C Curve
• Function: Overload & short circuit protection
• Application: High load electrical circuits
Construction & Design
The MCB is engineered for durability & efficient performance:
• High breaking capacity for heavy fault conditions
• C Curve characteristic suitable for moderate inrush loads
• Compact modular design for DIN rail mounting
• High-quality arc extinguishing mechanism
• Designed for consistent & reliable tripping performance
Safety & Protection
• Protects against overload & short circuit conditions
• High 15kA breaking capacity for enhanced safety
• Prevents damage to cables & connected equipment
• Improves system reliability & fault isolation
• Ensures safe operation of high load circuits
Mounting & Durability
• DIN rail mountable for easy installation
• Suitable for distribution boards & industrial panels
• Compact modular construction
• Designed for long electrical & mechanical life
• Reliable under frequent switching & fault conditions
Application Domains
• Residential distribution systems
• Commercial electrical installations
• Industrial control panels
• Motor & inductive load circuits
• High current distribution circuits
Key Features
• 80A rated MCB for high load applications
• Single pole (SP) design
• 15kA high breaking capacity
• C Curve for inductive & moderate inrush loads
• Reliable overload & short circuit protection
• DIN rail mountable compact design
• Durable & long-lasting construction
Applications
• Residential power distribution
• Commercial buildings
• Industrial electrical systems
• Motor circuits & machinery
• Distribution boards
FAQs
1. What does C Curve mean in this MCB?
Ans: It indicates the MCB is designed for circuits with moderate inrush currents, such as motors & inductive loads.
2. What is the significance of 15kA breaking capacity?
Ans: It means the MCB can safely interrupt very high fault currents up to 15kA.
3. Where is an 80A MCB used?
Ans: It is used in high load circuits in residential, commercial, & industrial installations.
4. Does this MCB provide overload protection?
Ans: Yes, it protects against both overload & short circuit conditions.
5. What does SP mean?
Ans: SP stands for single pole, meaning it protects one phase conductor.
6. How is this MCB installed?
Ans: It is installed on a DIN rail inside a distribution board.
7. Why is an MCB important?
Ans: It ensures electrical safety by automatically disconnecting faulty circuits & preventing damage to equipment.
Overview
| Discount Percentage | Between 0-10 % |
|---|---|
| Operating Temperature Range | -25°C to +60° C |
| Electrical life (Operating Cylces) | 5,000 |
| Tightening Torque | 4Nm |
| Termination capacity | 70 Sq. mm (Rigid) 50 Sq. mm (Flexible) |
| Mechanical Life (Operating Cycles) | 20,000 |
| No. of Poles | SP |
| Rated Insulation Voltage Ui (V) | 500V |
| Rated Frequency | 50Hz/60Hz |
| Rated Short-circuit Breaking Capacity | 15kA |
| Rated Impulse Voltage | 6kV |
| Current Rating | 80A |
| Rated operational voltage (Ue) | 240V |
| Conformance to Standards | IEC 60947-2 |
| Tripping Characteristic | C Curve |
| Length(mm) | 77.5 |
| Height(mm) | 100.6 |
| Breadth(mm) | 26.3 |
