Lauritz Knudsen AU Standard RCBO, 2 Pole, C Curve, Adi 10 kA, 100 mA, 63A, 240V | Suitable for isolation | with Added Immunity
Images:
Image 360:
How to video:
Further offers for this product
Incl. Tax
In Stock
No sellers found for this product.
Incl. Tax
Lauritz Knudsen AU Standard RCBO, 2 Pole, C Curve, Adi 10 kA, 100 mA, 63A, 240V | Suitable for isolation | with Added Immunity
- Description
- Specifications
- Documents
- Warranty
- Reviews
Description
About the Product
The AU RCBO 63A DP 240V ADI 10kA 100mA C Curve is a high capacity protection device that integrates MCB & RCCB functionality into a single compact unit. It is engineered to protect electrical circuits from overload, short circuit, & earth leakage faults while incorporating ADI (Advanced Detection Intelligence) technology for improved performance.
With a 63A current rating, this RCBO is ideal for high load applications such as main circuits, heavy appliances, & commercial installations. The 100mA leakage sensitivity is typically used for equipment protection & fire safety where higher leakage thresholds are acceptable.
How the RCBO Works
This RCBO operates as a combined protection system:
• Detects overload & short circuit faults similar to an MCB
• Detects earth leakage currents using advanced sensing technology
• Trips automatically when abnormal conditions occur
• Disconnects both live & neutral through double pole operation
The ADI technology enhances detection accuracy & reduces false tripping, ensuring reliable protection.
Electrical Configuration
• Rated current: 63A
• Poles: Double pole (DP)
• Rated voltage: 240V AC
• Technology: ADI (Advanced Detection / Intelligent leakage sensing)
• Breaking capacity: 10kA
• Sensitivity: 100mA
• Trip curve: C Curve
• Application: Overload, short circuit, & earth leakage protection
Construction & Design
The RCBO is designed for high performance & durability in demanding environments:
• Integrated MCB & RCCB functions in one device
• Advanced detection system for enhanced fault sensing
• Modular design compatible with DIN rail mounting
• Compact structure for efficient panel space usage
• High mechanical & electrical endurance
• Designed for consistent & accurate tripping performance
Safety & Protection
• Protects against overload & short circuit faults
• Detects earth leakage currents to protect equipment
• 100mA sensitivity suitable for fire prevention & system protection
• Double pole isolation ensures complete circuit disconnection
• Reduces risk of electrical hazards, fire, & equipment damage
Mounting & Durability
• DIN rail mounting for easy installation• Suitable for residential, commercial, & light industrial panels
• Compact modular construction
• Designed for frequent operation & fault handling
• Built for long term durability & reliable performance
Application Domains
• Main power distribution circuits (single phase)
• Commercial electrical installations
• High load appliance circuits
• Electrical distribution boards
• Equipment protection systems
Key Features
• 63A rated RCBO for high load circuits
• Double pole design for complete circuit isolation
• 10kA breaking capacity for reliable fault interruption
• 100mA sensitivity for equipment protection & fire safety
• ADI technology for advanced leakage detection
• C curve characteristic for general purpose applications
• Combines MCB & RCCB functions in one unit
• DIN rail compatible for easy installation
Applications
• Residential distribution boards
• Commercial electrical systems
• Main power circuits
• High load installations
• Equipment protection circuits
FAQs
1. What is ADI in this RCBO?
Ans: ADI stands for advanced detection technology that improves leakage current sensing accuracy & device reliability.
2. What does 100mA sensitivity indicate?
Ans: It indicates the leakage current level for tripping & is mainly used for equipment protection & fire safety rather than personal protection.
3. Why is a 63A RCBO used?
Ans: It is used for high load circuits such as main supply lines & heavy electrical equipment.
4. What is the advantage of double pole protection?
Ans: It disconnects both live & neutral, ensuring full circuit isolation during faults.
5. What does 10kA breaking capacity mean?
Ans: It represents the maximum fault current the device can safely interrupt.
6. What is a C curve characteristic?
Ans: It is suitable for circuits with moderate inrush currents such as appliances & general loads.
7. Where can this RCBO be used?
Ans: It is suitable for residential, commercial, & light industrial installations requiring reliable combined protection.
Overview
| Discount Percentage | Between 0-10 % |
|---|---|
| Operating Temperature Range | -25°C to +60°C |
| Electrical life (Operating Cylces) | 10,000 |
| Tightening Torque | 4Nm |
| Termination capacity | 35 Sq. mm (Rigid) 25 Sq. mm (Flexible) |
| Mechanical Life (Operating Cycles) | 20,000 |
| No. of Poles | DP |
| Rated Insulation Voltage Ui (V) | 500V |
| Rated Frequency | 50Hz |
| Rated Short-circuit Breaking Capacity | 10kA as per IEC 61009-1 |
| Rated Impulse Voltage | 6kV |
| Current Rating | 63A |
| Rated operational voltage (Ue) | 240V |
| Conformance to Standards | IEC 61009-1 |
| Tripping Characteristic | C Curve |
| Sensitivity | 100mA |
| Length(mm) | 77.5 |
| Height(mm) | 103.6 |
| Breadth(mm) | 70 |
