Electrical Contactors: How they work and what are they used for?

A contactor is an electrical relay used to control the flow of electric current in an electric motor or other high-power loads. It is a switch that is operated by an electromagnetic coil, allowing it to make or break electrical connections in a circuit. Contactors are commonly used in various applications where it is necessary to control the power supply to motors, heaters, lighting systems, and other high-current devices.

Key components of a contactor

Here are the key components and features of a typical contactor:

Electromagnetic Coil:

Electromagnetic coil is the part of the contactor that, when energised, generates a magnetic field. This magnetic field attracts the movable part of the contactor, causing it to close or open the electrical contacts.

Contacts:

Contacts are the switch-like elements within the contactor that physically make or break electrical connections. In a motor control application, a contactor typically has at least two sets of contacts: the main power contacts and the auxiliary contacts.

Main Power Contacts:

These are the contacts responsible for carrying the heavy current required to power the load, such as an electric motor.

Auxiliary Contacts:

These are additional contacts used for control purposes, signalling, or interfacing with other devices. They are often used in coordination with control circuits to perform auxiliary functions.

Enclosure:

Contactors are housed in enclosures that provide protection against environmental factors like dust and moisture. The enclosure also helps to ensure safety by preventing accidental contact with live electrical components.

Coil Terminals:

These terminals are used to connect the electromagnetic coil to the control circuit. When electrical power is applied to the coil, it generates a magnetic field that actuates the contacts.

Arc Suppression Mechanism:

To prevent arcing (sparking) between the contacts when they open or close, contactors often include features like arc chutes or other mechanisms designed to extinguish the arc quickly.

AC Contactors vs DC Contactors

AC (alternating current) and DC (direct current) contactors are both electromechanical devices used to control the flow of electrical power in a circuit. However, there are differences between them based on their design and application characteristics. Here are some key distinctions between AC and DC contactors:

Type of Current:

• AC Contactors: AC Contactors are designed for controlling alternating current, typically found in applications where AC motors are used.
• DC Contactors: DC Contactors are specifically designed for controlling direct current, often used in applications involving DC motors or other DC loads.

Voltage Ratings:

• AC Contactors: Have AC coils, which are usually designed to operate on standard AC voltages (e.g., 120VAC, 240VAC, 480VAC).
• DC Contactors: Have DC coils, designed to operate on DC voltages (e.g., 12VDC, 24VDC).

Arc Suppression:

• AC Contactors: Due to the nature of AC, the current naturally passes through zero during each cycle, which helps in extinguishing the arc when the contacts open. AC contactors typically do not require additional arc suppression devices.
• DC Contactors: DC circuits do not naturally extinguish arcs when the contacts open. Therefore, DC contactors may require additional arc suppression mechanisms, such as arc chutes or magnetic blowouts, to safely interrupt the current.

Construction and Design:

• AC Contactors: Constructed to handle the characteristics of alternating current, including the periodic zero-crossings. They often have a simpler design compared to DC contactors.
• DC Contactors: Designed to handle the continuous and unidirectional flow of direct current. DC contactors may have additional features to deal with challenges like arcing and higher wear on the contacts.

Applications:

• AC Contactors: Commonly used in applications where AC motors and loads are prevalent, such as in industrial machinery, heating systems, air conditioning, and lighting control.
• DC Contactors: Used in applications involving DC motors, battery systems, and other DC-powered devices. Examples include electric vehicles, renewable energy systems, and certain industrial processes.

Common electrical equipment used in sync with contactors

Contactors are commonly used in conjunction with various electrical equipment to create comprehensive control systems for different applications. Here are some common electrical equipment and components that are often used in sync with contactors:

Starters:

Motor starters are devices that incorporate contactors along with overload relays, usually in a single unit. Starters are used to control the starting and stopping of electric motors, providing protection against overloads.

Overload Relays:

Overload relays are protective devices that are connected to contactors or starters to monitor the current drawn by a motor. If the current exceeds a preset level, the overload relay opens the circuit to protect the motor from damage due to overheating.

Push Buttons and Pilot Devices:

Push buttons, selector switches, and other pilot devices are used to manually control the operation of contactors and other electrical equipment. They are often part of the control panel for easy user interaction.

Timers:

Timers are used to introduce time-delay functions in control circuits. They can be employed in coordination with contactors to control the duration of certain operations or to implement time-based sequences.

Control Relays:

Control relays are devices that enable a low-power control circuit to switch a higher-power circuit. They are often used in control panels in conjunction with contactors to provide additional control functions.

Disconnect Switches:

Disconnect switches, also known as isolators, are used to disconnect electrical equipment from the power source. They can be part of the overall control system to ensure the safety of maintenance personnel.

Variable Frequency Drives (VFDs):

VFDs are electronic controllers that can adjust the speed and torque of an AC motor by controlling the frequency and voltage. Contactors may be used in combination with VFDs to control the power supply to the motor.

Transformers:

Transformers are used to change voltage levels in electrical systems. They may be integrated into the control circuit to match the voltage requirements of the contactors and other equipment.

Control Panels:

Control panels house and organise various components, including contactors, starters, relays, and other devices, into a single enclosure. They provide a centralised location for controlling and monitoring electrical equipment.

Sensors and Switches:

Proximity sensors, limit switches, and other types of sensors can be integrated with contactors to provide feedback or trigger certain actions based on the operating conditions. These components work together to create a reliable and efficient control system for various applications, such as motor control in industrial settings, HVAC systems, lighting control, and more. The specific combination of equipment depends on the requirements of the application and the desired functionality of the control system.
