Lauritz Knudsen Manual Changeover Switch, C-Line, 125A, 415V AC | Frame 2 | 4 Pole | SS Enclosure Extended Handle| Load‑Handling Capability
- Description
- Specifications
- Documents
- Warranty
- Reviews
Description
About the Product
The Lauritz Knudsen C-Line Manual Changeover Switch FR2 125A 4P 415V AC with SS (stainless steel) enclosure is a heavy-duty & reliable switching solution designed for safe transfer of electrical load between two power sources such as mains supply & generator backup.
This model features a robust stainless steel enclosure that provides superior protection against dust, moisture, corrosion, & harsh environmental conditions. The extended handle allows smooth & safe external operation without opening the enclosure, improving convenience & operator safety.
Being part of the FR2 series, it offers enhanced durability & performance compared to standard variants, making it well-suited for more demanding industrial & commercial installations. The 4-pole (4P) configuration ensures complete isolation of all conductors including neutral, ensuring maximum safety & reliability.
Purpose & Function
This enclosed manual changeover switch is designed for reliable & safe power management:
• Transfers load between mains & generator supply
• Provides complete circuit isolation during switching
• Enables external manual operation using an extended handle
• Ensures uninterrupted power availability
• Enhances operational safety with protective enclosure
Electrical Configuration
• Type: Manual Changeover Switch
• Series: C-Line FR2
• Current rating: 125A
• Rated voltage: 415V AC
• Poles: 4 Pole (4P)
• Enclosure: Stainless Steel (SS)
• Operation: Extended handle
• Function: Power source switching & isolation
Construction & Design
The switch is engineered for durability & industrial performance:
• Stainless steel enclosure for corrosion resistance & strength
• Heavy-duty construction for long service life
• Extended handle for convenient external operation
• Compact & robust design suitable for industrial panels
• High-quality contact system for reliable switching performance
Safety & Protection
• SS enclosure protects against dust, moisture, & environmental damage
• 4-pole design ensures complete electrical isolation
• Reduces risk of electrical faults & accidental contact
• Improves operator safety during switching
• Ensures dependable performance in harsh environments
Mounting & Installation
• Suitable for wall or panel mounting
• Enclosed design allows use in exposed & semi-outdoor environments
• Extended handle enables operation without opening the enclosure
• Compatible with standard industrial electrical systems
• Supports secure & organized wiring setup
Application Domains
• Industrial power distribution systems
• Commercial buildings & infrastructure
• Generator backup systems
• Outdoor & semi-outdoor electrical installations
• Electrical control panels in harsh environments
• Manufacturing & processing units
Key Features
• 125A current rating for medium to high-load applications
• 415V AC operation for three phase systems
• 4-pole configuration for complete circuit isolation
• Stainless steel enclosure for enhanced protection
• Extended handle for safe & convenient external operation
• Durable & industrial-grade construction
Applications
• Generator changeover panels
• Industrial distribution boards
• Commercial electrical installations
• Outdoor electrical systems
• Backup power management solutions
FAQs
1. What is the advantage of an SS enclosure?
Ans: The stainless steel enclosure protects the switch from dust, moisture, corrosion, & physical damage, making it suitable for harsh environments.
2. What does 4P mean?
Ans: 4P (four-pole) means all conductors including neutral are isolated for maximum safety.
3. What is the purpose of the extended handle?
Ans: It allows the switch to be operated externally without opening the enclosure, improving safety & ease of use.
4. Can this switch be used outdoors?
Ans: Yes, the SS enclosed design makes it suitable for outdoor or semi-outdoor installations.
5. What is a manual changeover switch used for?
Ans: It is used to safely transfer power between two sources such as mains & generator.
6. Why is complete isolation important?
Ans: It ensures safety during switching & maintenance by fully disconnecting the circuit.
7. Is this suitable for industrial applications?
Ans: Yes, it is designed for industrial, commercial, & backup power systems requiring safe & reliable switching.
Overview
| Rated Operational Current (A) | 125 |
|---|---|
| Conformance to Standards | IS/IEC 60947-3, EN 60947-3 |
| Utilization Category | AC-23A |
| Rated operational voltage (Ue) | 415V |
| Operating Frequency(Hz) | 50/60 |
| Mechanical Life (No. of operating cycles) | 16000 |
| Rated Insulation Voltage Ui (V) | 1000 |
| Short Time Withstand for 1sec (kA) | 8 |
| Rated Operational Power (kW) | 65 |
| Rated Breaking Capacity@AC-23A (A) | 1000 |
| Rated Making Capacity@AC-23A (A) | 1250 |
| Version | Manual, SS enclosure |
| No. of Poles | 4P |
| Electrical life (Operating Cylces) | 2000 |
| Mechanical Life (Operating Cycles) | 16000 |
| Maximum Al termination (sq.mm) | 95 |
| Standard Accessories | Terminal Shroud,Phase Barriers,Source Separator, Extended handle with shaft |
| Pollution Degree | 3 |
| Rated impulse withstand voltage (Uimp) | 12 |
| Discount Percentage | Between 0-10 % |
