DN1C MCCB 125 3P 415V AC 25kA Thermal Magnetic 50/60 Hz
Note: L&T Switchgear Business is now Lauritz Knudsen Electrical & Automation.
Some products may still be labelled as L&T Switchgear Business until existing stock lasts. The quality and service you trust remain unchanged.
The dsineDN series is distinguished by its state-of-the-art design, user-friendly features, and a diverse range of protection releases, making it stand out in the market. Recognized for its ergonomic design, aesthetics, and compactness, it represents a new era in MCCBs (Molded Case Circuit Breakers).
Specially crafted and developed for extreme tropical conditions, this series ensures reliable performance in high ambient and humid environments. The dsineDN Series complies with the latest standards such as IS/IEC 60947-2, IEC 60947-2, and EN 60947-2. It holds NABL accreditation, and our products conform to international standards, carrying the prestigious CE marking.
dsine consistently meets the ever-evolving needs of customers, informed by in-depth analysis and customer feedback. Understanding our customers' requirements and demands, our contemporary range of MCCBs always aims to ensure complete customer satisfaction. Enhanced by a variety of accessories, the dsine range provides comprehensive solutions for customer applications, guaranteeing operational safety, reliability, and versatility.
-
Rated Operational Current125
-
Mechanical Life (No. of operating cycles)25000
-
No. of Poles3P
-
Rated Operational voltage (Ue)415V AC
-
Rated Insulation Voltage Ui (V)800 V
-
Conformance to StandardsIEC 60947-1, EN 60947-1, IS/IEC 60947-1 IEC 60947-2, EN 60947-2, IS/IEC 60947-2 IEC 60947-3, EN 60947-3, IS/IEC 60947-3 IEC 60947-4, EN 60947-4, IS/IEC 60947-4
-
Rated impulse withstand voltage (Uimp)8 kV
-
Operational Frequency (Hz)50/60 Hz
-
Release TypeTM
-
Rated Short Circuit Breaking capacity Icu(kA)DN1C MCCB 125 3P 415V AC 25kA Thermal Magnetic 50/60 Hz
-
Rated Sevice circuit breaking capacity (Ics as % of Icu) @415VAC25kA
-
Ambient temperature-5°C to 55°C
-
Suitable for isolationYes
-
Load-line biasNo
-
Electrical Life (Operating Cycles)10000
-
IP ProtectionIP40
-
Pollution DegreeIII
-
Width(mm)105
-
Height(mm)165
-
Depth(mm)60
