Lauritz Knudsen DN2S, MCCB, 4 Pole, 415V AC, 70kA Breaking Capacity, 63A | Microprocessor Release MTX2.0 | IP40 Protection
Images:
Image 360:
How to video:
Further offers for this product
Incl. Tax
In Stock
No sellers found for this product.
Incl. Tax
Lauritz Knudsen DN2S, MCCB, 4 Pole, 415V AC, 70kA Breaking Capacity, 63A | Microprocessor Release MTX2.0 | IP40 Protection
- Description
- Specifications
- Documents
- Warranty
- Reviews
Description
About the Product
The Lauritz Knudsen DN2S MCCB 63A 4 Pole 415V AC 70kA MTX2.0 Thermal Magnetic is a robust molded case circuit breaker engineered to provide advanced protection & switching for low-voltage electrical distribution systems. Designed to safeguard circuits against overloads & short-circuit faults, it helps protect motors, transformers, cables, switchboards, & electrical equipment from damage caused by abnormal operating conditions.
Featuring a 63A rated current, 4 Pole configuration, 415V AC operating voltage, & an exceptionally high 70kA short-circuit breaking capacity, this MCCB is suitable for industrial facilities, commercial buildings, infrastructure projects, OEM panels, & electrical distribution systems where maximum fault interruption capability, equipment protection, & complete isolation of phase & neutral conductors are required.
The integrated MTX2.0 thermal magnetic trip unit combines thermal overload protection & instantaneous magnetic short-circuit protection, ensuring fast fault detection, reliable interruption, enhanced electrical safety, & dependable system performance.
How the Mechanism Works
The product functions by:
• Protecting circuits against overload conditions
• Interrupting extremely high short-circuit fault currents
• Automatically disconnecting faulty circuits
• Protecting motors, transformers, cables, & electrical equipment
• Providing complete phase & neutral conductor isolation
• Supporting safe & reliable power distribution
• Reducing risks of electrical damage
• Delivering dependable fault-clearing performance
It serves as a critical protection device for maintaining the safety & continuity of electrical distribution systems.
Electrical Configuration
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: DN2S
• Current Rating: 63A
• Pole Configuration: 4 Pole
• Rated Voltage: 415V AC
• Frequency: 50/60 Hz
• Breaking Capacity: 70kA
• Trip Unit: MTX2.0 Thermal Magnetic
• Application: Circuit Protection & Switching
• Suitable For: Three-Phase & Neutral Electrical Systems
• Catalog Number: CM92164OOOOAG
Construction & Design
Designed for dependable protection:
• MTX2.0 thermal magnetic trip mechanism
• 63A rated current capacity
• 4-pole protection configuration
• Neutral pole switching capability
• 70kA short-circuit breaking capability
• Durable molded case construction
• Reliable contact system
• Compact industrial-grade design
• Long operational service life
Safety & Protection
• Reliable overload protection
• Fast short-circuit interruption
• Extremely high fault-clearing capability
• Enhanced electrical safety
• Complete phase & neutral isolation
• Improved equipment protection
• Reduced operational downtime
• Long-term system reliability
• Consistent performance under demanding conditions
Mounting & Durability
• Suitable for electrical distribution panels
• Compatible with industrial switchboards & OEM panels
• Rugged molded case construction
• High mechanical endurance
• Designed for continuous operation
• Low maintenance requirements
• Quality manufacturing standards
• Suitable for industrial environments
Application Domains
• Industrial Facilities
• Manufacturing Plants
• Commercial Buildings
• OEM Control Panels
• Infrastructure Projects
• Utility Installations
• Electrical Distribution Panels
• Power Management Systems
Key Features
• DN2S MCCB series
• 63A current rating
• 4 Pole configuration
• 415V AC operation
• 70kA breaking capacity
• MTX2.0 thermal magnetic trip unit
• Overload protection
• Short-circuit protection
• Neutral pole switching capability
• Long service life
Applications
• Three-phase power distribution
• Feeder circuit protection
• Industrial machinery protection
• Motor circuit protection
• Commercial electrical systems
• OEM equipment panels
• Infrastructure electrical projects
• Equipment circuit protection
FAQs
1. What is the CM92164OOOOAG MCCB used for?
Ans: It is used for protecting electrical circuits & connected equipment against overloads & short circuits in three-phase electrical systems with neutral isolation capability.
2. What is the current rating of this MCCB?
Ans: The MCCB is rated at 63A.
3. What does 4 Pole mean?
Ans: A 4 Pole MCCB protects & switches all three phase conductors along with the neutral conductor, ensuring complete circuit isolation & enhanced electrical safety.
4. What is the breaking capacity of this MCCB?
Ans: It provides a 70kA short-circuit breaking capacity, enabling safe interruption of extremely high fault currents & protection of connected equipment.
5. What is the MTX2.0 trip unit?
Ans: The MTX2.0 thermal magnetic trip unit combines thermal overload protection with instantaneous magnetic protection against short-circuit faults.
6. Where can this MCCB be installed?
Ans: It can be installed in electrical distribution panels, industrial switchboards, OEM machinery panels, commercial facilities, & infrastructure projects.
7. Why choose a 4 Pole MCCB instead of a 3 Pole MCCB?
Ans: A 4 Pole MCCB provides simultaneous switching of the neutral conductor along with all three phases, ensuring complete isolation & improved safety in three-phase electrical systems.
8. Does it require frequent maintenance?
Ans: No, its rugged molded case construction & reliable protection mechanism ensure long-term, low-maintenance operation under normal operating conditions.
Overview
| Rated Operational Current | 63 |
|---|---|
| Mechanical Life (No. of operating cycles) | 25000 |
| No. of Poles | 4P |
| Rated Operational voltage (Ue) | 415V AC |
| Rated Insulation Voltage Ui (V) | 800 V |
| Conformance to Standards | IEC 60947-1, EN 60947-1, IS/IEC 60947-1 IEC 60947-2, EN 60947-2, IS/IEC 60947-2 IEC 60947-3, EN 60947-3, IS/IEC 60947-3 IEC 60947-4, EN 60947-4, IS/IEC 60947-4 |
| Rated impulse withstand voltage (Uimp) | 8 kV |
| Operational Frequency (Hz) | 50/60 Hz |
| Release Type | MTX2.0 |
| Rated Short Circuit Breaking capacity Icu(kA) | DN2S MCCB 63 4P 415V AC 70kA MTX2.0 50/60 Hz |
| Rated Sevice circuit breaking capacity (Ics as % of Icu) @415VAC | 70kA |
| Ambient temperature | -5°C to 55°C |
| Suitable for isolation | Yes |
| Load-line bias | No |
| Electrical Life (Operating Cycles) | 10000 |
| IP Protection | IP40 |
| Pollution Degree | III |
| Width(mm) | 140 |
| Height(mm) | 179 |
| Depth(mm) | 96 |
