Lauritz Knudsen DN3-630SD, MCCB, 4 Pole, 415V AC, 630A | Switch Disconnector | IP40 Protection | MCCBs without protection release
Images:
Image 360:
How to video:
Further offers for this product
Incl. Tax
In Stock
No sellers found for this product.
Incl. Tax
Lauritz Knudsen DN3-630SD, MCCB, 4 Pole, 415V AC, 630A | Switch Disconnector | IP40 Protection | MCCBs without protection release
- Description
- Specifications
- Documents
- Warranty
- Reviews
Description
About the Product
The Lauritz Knudsen DN3-630SD MCCB 630A 4 Pole 415V AC Magnetic Trip is a robust molded case circuit breaker engineered to provide dependable protection & switching for low-voltage electrical distribution networks. Designed to safeguard electrical equipment against short-circuit faults, it helps protect motors, transformers, power distribution panels, cables, & switchboards from severe electrical disturbances.
Featuring a 630A rated current, 4 Pole configuration, & 415V AC operating voltage, this MCCB is suitable for industrial facilities, manufacturing plants, commercial buildings, OEM equipment, utility installations, & infrastructure projects where dependable fault isolation & reliable switching performance are required.
Its magnetic trip mechanism provides instantaneous tripping during short-circuit conditions, enabling rapid fault clearing, improved equipment protection, reduced downtime, & enhanced system safety. The 4 Pole configuration ensures simultaneous switching of all three phases & the neutral conductor for complete circuit isolation.
How the Mechanism Works
The product functions by:
• Detecting short-circuit fault currents instantly
• Interrupting fault conditions rapidly
• Automatically disconnecting faulty circuits
• Protecting motors, transformers, & cables
• Providing complete phase & neutral isolation
• Preventing damage to electrical systems
• Supporting safe power distribution
• Delivering reliable fault-clearing performance
It serves as a critical protection & switching device for maintaining electrical safety & system reliability.
Electrical Configuration
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: DN3-630SD
• Current Rating: 630A
• Pole Configuration: 4 Pole
• Rated Voltage: 415V AC
• Frequency: 50/60 Hz
• Trip Type: Magnetic Trip
• Application: Short-Circuit Protection & Switching
• Suitable For: Three-Phase & Neutral Electrical Systems
• Catalog Number: CM96807OOTOOG
Construction & Design
Designed for dependable protection:
• Instantaneous magnetic trip mechanism
• 630A current carrying capacity
• 4-pole switching configuration
• Neutral pole switching capability
• Industrial-grade molded case design
• Durable contact assembly
• Reliable switching operation
• Robust mechanical construction
Safety & Protection
• Fast fault interruption capability
• Enhanced short-circuit protection
• Improved electrical safety
• Complete phase & neutral isolation
• Reduced equipment damage risk
• Reliable switching performance
• Improved system uptime
• Stable long-term operation
Mounting & Durability
• Suitable for switchboards & distribution panels
• Compatible with industrial & commercial installations
• Rugged molded case construction
• High mechanical endurance
• Designed for continuous-duty operation
• Low maintenance requirements
• Quality-engineered construction
• Suitable for demanding environments
Application Domains
• Industrial Facilities
• Manufacturing Plants
• Commercial Buildings
• Utility Installations
• Infrastructure Projects
• Electrical Distribution Systems
• OEM Control Panels
• Power Management Applications
Key Features
• DN3-630SD MCCB series
• 630A current rating
• 4 Pole configuration
• 415V AC operation
• Magnetic trip protection
• Instantaneous short-circuit protection
• Neutral pole switching capability
• Reliable switching functionality
• Industrial-grade construction
• Long service life
Applications
• Three-phase power distribution
• Main incomer protection
• Feeder circuit protection
• Industrial machinery protection
• Motor protection systems
• Transformer protection circuits
• OEM panel applications
• Infrastructure electrical projects
FAQs
1. What is the CM96807OOTOOG MCCB used for?
Ans: It is used for short-circuit protection & switching in three-phase electrical distribution systems requiring neutral isolation capability.
2. What is the current rating of this MCCB?
Ans: The MCCB is rated at 630A.
3. What does 4 Pole mean?
Ans: A 4 Pole MCCB protects & switches all three phase conductors along with the neutral conductor, ensuring complete circuit isolation.
4. What is a magnetic trip MCCB?
Ans: A magnetic trip MCCB provides instantaneous tripping in response to short-circuit currents, helping rapidly isolate faults & protect equipment.
5. What voltage is this MCCB designed for?
Ans: It is designed for operation in 415V AC electrical systems.
6. Where can this MCCB be installed?
Ans: It can be installed in switchboards, distribution panels, industrial facilities, commercial buildings, OEM equipment, & infrastructure projects.
7. Why choose a 4 Pole MCCB instead of a 3 Pole MCCB?
Ans: A 4 Pole MCCB provides simultaneous switching of the neutral conductor together with all three phases, offering complete isolation & enhanced electrical safety.
8. Does it require frequent maintenance?
Ans: No, the durable molded case construction & reliable operating mechanism provide long-term, low-maintenance service under normal operating conditions.
Overview
| Rated Operational Current | 630 |
|---|---|
| Mechanical Life (No. of operating cycles) | 15000 |
| No. of Poles | 4P |
| Rated Operational voltage (Ue) | 415V AC |
| Rated Insulation Voltage Ui (V) | 800 V |
| Conformance to Standards | IEC 60947-1, EN 60947-1, IS/IEC 60947-1 IEC 60947-2, EN 60947-2, IS/IEC 60947-2 IEC 60947-3, EN 60947-3, IS/IEC 60947-3 IEC 60947-4, EN 60947-4, IS/IEC 60947-4 |
| Rated impulse withstand voltage (Uimp) | 8 kV |
| Operational Frequency (Hz) | 50/60 Hz |
| Release Type | SD |
| Rated Short Circuit Breaking capacity Icu(kA) | DN3-630SD MCCB 630 4P 415V AC - SD 50/60 Hz |
| Ambient temperature | -5°C to 55°C |
| Suitable for isolation | Yes |
| Load-line bias | No |
| Electrical Life (Operating Cycles) | 4000 |
| IP Protection | IP40 |
| Pollution Degree | III |
| Width(mm) | 183.5 |
| Height(mm) | 266 |
| Depth(mm) | 111.5 |
