Lauritz Knudsen DY125U, MCCB, 3 Pole, 415V AC, 10kA Breaking Capacity, 100A | Thermal-Magnetic Release | Long Electrical & Mechanical Life | with Spreader Terminals
Images:
Image 360:
How to video:
Further offers for this product
Incl. Tax
In Stock
No sellers found for this product.
Incl. Tax
Lauritz Knudsen DY125U, MCCB, 3 Pole, 415V AC, 10kA Breaking Capacity, 100A | Thermal-Magnetic Release | Long Electrical & Mechanical Life | with Spreader Terminals
- Description
- Specifications
- Documents
- Warranty
- Reviews
Description
About the Product
The Lauritz Knudsen EM90983OOKO from the DY125U series is a compact & economical 3 Pole Moulded Case Circuit Breaker (MCCB) designed to provide dependable circuit protection for residential, commercial, & light industrial electrical applications. Rated at 100A & 415V AC, this MCCB safeguards electrical circuits, wiring systems, & connected equipment against overloads & short-circuit faults while ensuring reliable operation & enhanced electrical safety.
The breaker incorporates an advanced thermal-magnetic trip mechanism that provides dual protection against electrical abnormalities. The thermal protection element offers time-delayed tripping during overload conditions, helping prevent overheating, insulation degradation, & damage to cables & connected devices caused by prolonged overcurrent situations. The magnetic protection element responds instantaneously to short-circuit faults, rapidly disconnecting the affected circuit & minimizing damage to electrical systems & equipment.
With a breaking capacity of 10kA, the DY125U MCCB is specifically designed for installations with low fault levels. This interruption capability makes it an ideal solution for small-scale power distribution systems where high fault current interruption ratings are not required. The breaker delivers a practical combination of affordability, safety, & protection performance for everyday electrical installations.
A key advantage of this variant is the inclusion of spreader terminals, which improve cable management & installation flexibility. Spreader terminals allow easier termination of larger or multiple conductors, improve current distribution, & ensure secure electrical connections. This feature enhances installation efficiency, wiring convenience, & overall system reliability.
The 3 Pole configuration is intended for three-phase electrical systems commonly used in residential complexes, commercial facilities, utility installations, & light industrial applications. Designed for operation at 50/60 Hz, it ensures compatibility with standard electrical networks worldwide.
Manufactured with a compact & durable design, the MCCB enables easy installation in electrical panels, distribution boards, switchgear assemblies, & control systems where panel space optimization is important. Despite its compact construction, the breaker delivers dependable performance & consistent protection for low to moderate-load electrical circuits.
The DY125U series is recognized as an economical protection solution, making it particularly suitable for users seeking reliable circuit protection in applications with lower fault levels & limited installation space.
This 100A MCCB with spreader terminals is an excellent choice for applications requiring higher current handling capability, enhanced cable connectivity, dependable safety, & cost-effective operation.
How the Mechanism Works
The product functions by:
• Continuously monitoring electrical current flowing through the circuit
• Detecting overload conditions using a thermal trip mechanism
• Providing delayed tripping during sustained overcurrent conditions
• Detecting short-circuit faults using a magnetic trip system
• Instantly disconnecting the circuit during fault conditions
• Protecting cables, conductors, & connected equipment from damage
• Preventing overheating caused by excessive current flow
• Supporting safe & reliable power distribution
• Improving electrical safety in low-load installations
• Enhancing wiring flexibility using spreader terminals
It serves as a dependable protection device for residential, commercial, & light industrial electrical systems.
Electrical Configuration
• Product Type: Moulded Case Circuit Breaker (MCCB)
• Model: EM90983OOKO
• Series: DY125U
• Pole Configuration: 3 Pole
• Rated Current: 100A
• Rated Voltage: 415V AC
• Frequency: 50/60 Hz
• Breaking Capacity: 10kA
• Trip Unit Type: Thermal Magnetic
• Terminal Type: Spreader Terminals Included
• Mounting Type: Panel Mounted
• Primary Function: Overload & Short-Circuit Protection
• Application: Electrical Distribution & Equipment Protection
Construction & Design
Designed for durability & dependable operation:
• Compact MCCB construction
• Lightweight & robust design
• High-strength moulded insulating enclosure
• Precision-engineered operating mechanism
• Thermal-magnetic trip technology
• Durable contact system
• Efficient arc interruption chamber
• Integrated spreader terminals
• Secure terminal connection arrangement
• Long operational service life
Safety & Protection
• Reliable overload protection
• Instantaneous short-circuit protection
• 10kA fault interruption capability
• Enhanced electrical safety
• Improved protection for connected equipment
• Reduced risk of electrical damage
• Stable & dependable operation
• Better cable management & connectivity
• Economical protection solution
• Reduced maintenance requirements
Mounting & Durability
• Easy installation in compact electrical panels
• Suitable for distribution boards & switchgear systems
• Space-saving footprint for panel integration
• Secure mounting arrangement
• Lightweight & durable construction
• Designed for continuous-duty operation
• Reliable performance in everyday applications
• Enhanced wiring flexibility with spreader terminals
• Long operational lifespan
• Minimal maintenance requirements
Application Domains
• Residential Electrical Distribution Panels
• Small Commercial Installations
• Light Industrial Systems
• Switchgear & Control Panels
• Installations Requiring Flexible Cable Termination
• Low to Moderate Load Power Distribution Networks
• Utility Electrical Systems
• Three-Phase Electrical Installations
• Equipment Protection Circuits
• General Electrical Protection Applications
Key Features
• Rated current of 100A
• 3 Pole configuration for three-phase systems
• Rated voltage of 415V AC
• Breaking capacity of 10kA
• Thermal-magnetic trip protection
• Reliable overload & short-circuit protection
• Supplied with spreader terminals for enhanced connectivity
• Improved cable termination & current distribution
• Suitable for 50/60 Hz operation
• Compact & durable construction
• Cost-effective solution for low fault-level applications
• Dependable long-term performance
Applications
• Residential electrical distribution panels
• Small commercial installations
• Light industrial systems
• Switchgear & control panels
• Installations requiring flexible cable termination
• Low to moderate load power distribution systems
• Utility electrical applications
• Equipment & machinery protection
• Three-phase electrical networks
• General-purpose distribution systems
FAQs
1. What is the advantage of spreader terminals?
Ans: Spreader terminals allow easier connection of larger or multiple cables, improving installation flexibility, current distribution, & connection reliability.
2. What is the current rating of this MCCB?
Ans: The MCCB has a rated current of 100A.
3. What type of protection does it provide?
Ans: It provides thermal protection against overload conditions & magnetic protection against short-circuit faults.
4. What is the breaking capacity of this MCCB?
Ans: The breaker has a breaking capacity of 10kA for safe interruption of fault currents in low fault-level installations.
5. Where is this MCCB typically used?
Ans: It is commonly used in residential, commercial, & light industrial systems where flexible cable termination & reliable protection are required.
6. How does this differ from the standard DY125U MCCB?
Ans: This version includes spreader terminals, providing enhanced cable connection flexibility, easier installation, & improved current distribution compared to standard terminal configurations.
7. Is this MCCB suitable for three-phase systems?
Ans: Yes, the 3 Pole configuration is specifically designed for three-phase electrical applications.
8. What are the advantages of a compact MCCB design?
Ans: A compact design saves panel space, simplifies installation, supports efficient electrical layouts, & makes the breaker ideal for distribution boards & confined installations.
Overview
| Rated Operational Current (A) | 100A |
|---|---|
| No. of Poles | 3P |
| Rated Operational voltage (Ue) | 415V AC |
| Rated Insulation Voltage Ui (V) | 800 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
| Operational Frequency (Hz) | 50/60 Hz |
| Release Type | Thermal Magnetic |
| Rated Short Circuit Breaking capacity Icu(kA) | 10kA |
| Rated Sevice circuit breaking capacity (Ics as % of Icu) @415VAC | 100% |
| Ambient temperature | -5°C to 55°C |
| Conformance to Standards | IS 60947-2, IEC 60947-2 & EN 60947-2 |
| Suitable for isolation | Yes |
| Load-line bias | No |
| Electrical Life (Operating Cycles) | 8000 |
| Mechanical Life (Operating Cycles) | 30000 |
| IP Protection | IP40 |
| Pollution Degree | III |
| Width(mm) | 75 |
| Height(mm) | 130 |
| Depth(mm) | 60 |
| Discount Percentage | Between 0-10 % |
