DY125U MCCB 80A 3P 415V AC 10kA Thermal Magnetic 50/60 Hz with Spreader Terminals

In stock
SKU
EM90983OOJO
₹2,430.00
( Prices are all inclusive of taxes )
DY125U MCCB 80A 3P 415V AC 10kA Thermal Magnetic 50/60 Hz with Spreader Terminals

HSN Code - 85362020

The price of the product is indicative and is subject to change as per batch, revision in prices at the time of delivery. Please refer to the final landing price for your reference.

Note: L&T Switchgear Business is now Lauritz Knudsen Electrical & Automation.
Some products may still be labelled as L&T Switchgear Business until existing stock lasts. The quality and service you trust remain unchanged.

CHECK DELIVERY TIME & COD AVAILABILITY

  • The DY Series, a new generation of MCCBs, stands out due to its state-of-the-art design, contemporary user-friendly features, ergonomics, aesthetics and compactness.
  • DY Series complies with the latest standards like IS/IEC 60947-2, IEC 60947-2 & EN 60947-2.
  • The range is specially designed for tropical conditions, ensuring reliable performance at high ambient and humid environments.
  • The range can satisfy the most demanding system requirements.
  • The DY Series, having a wide range of accessories, ensures operational safety, reliability and versatility.
  • The products conform to international standards, carry CE marking.
  • Rated Operational Current (A)
    80A
  • No. of Poles
    3P
  • Rated Operational voltage (Ue)
    415V AC
  • Rated Insulation Voltage Ui (V)
    800 V
  • Rated impulse withstand voltage (Uimp)
    8 kV
  • Operational Frequency (Hz)
    50/60 Hz
  • Release Type
    Thermal Magnetic
  • Rated Short Circuit Breaking capacity Icu(kA)
    10kA
  • Rated Sevice circuit breaking capacity (Ics as % of Icu) @415VAC
    100%
  • Ambient temperature
    -5°C to 55°C
  • Conformance to Standards
    IS 60947-2, IEC 60947-2 & EN 60947-2
  • Suitable for isolation
    Yes
  • Load-line bias
    No
  • Electrical Life (Operating Cycles)
    8000
  • Mechanical Life (Operating Cycles)
    30000
  • IP Protection
    IP40
  • Pollution Degree
    III
  • Width(mm)
    75
  • Height(mm)
    130
  • Depth(mm)
    60
