Lauritz Knudsen DZ1N, MCCB, 3 Pole, 415V AC, 50kA Breaking Capacity, 100A | Microprocessor Release iTRP1 | IP40 Protection
- Description
- Specifications
- Documents
- Warranty
- Reviews
Description
About the Product
The Lauritz Knudsen DZ1N MCCB 100A 3 Pole 415V AC 50kA ITRP1 is a robust molded case circuit breaker engineered to provide comprehensive protection & switching for low-voltage electrical installations. Designed to safeguard circuits against overloads & short-circuit faults, it helps protect motors, cables, switchboards, control panels, machinery, & power distribution systems from damage caused by abnormal current conditions.
Featuring a 100A rated current, 3 Pole configuration, 415V AC operating voltage, & a 50kA short-circuit breaking capacity, this MCCB is suitable for industrial facilities, commercial buildings, OEM machinery, infrastructure projects, & utility applications requiring dependable protection & switching performance.
The integrated ITRP1 trip unit provides accurate protection against overload & fault conditions while ensuring reliable operation, improved system safety, & enhanced equipment protection.
How the Mechanism Works
The product functions by:
• Monitoring circuit current continuously
• Detecting overload conditions promptly
• Interrupting short-circuit fault currents
• Automatically disconnecting faulty circuits
• Protecting motors, cables, & equipment
• Supporting safe power distribution
• Reducing equipment damage risks
• Improving overall system reliability
It serves as a critical protection & switching device within low-voltage electrical power systems.
Electrical Configuration
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: DZ1N
• Current Rating: 100A
• Pole Configuration: 3 Pole
• Rated Voltage: 415V AC
• Frequency: 50/60 Hz
• Breaking Capacity: 50kA
• Trip Unit: ITRP1
• Application: Circuit Protection & Switching
• Suitable For: Three-Phase Electrical Systems
• Catalog Number: DZ1T0100NXF1AOOOO
Construction & Design
Designed for dependable protection:
• Integrated ITRP1 trip unit
• 100A current carrying capacity
• 3-pole switching configuration
• 50kA fault interruption capability
• Durable molded case construction
• Reliable contact assembly
• Industrial-grade engineering
• Long operational lifespan
Safety & Protection
• Reliable overload protection
• Effective short-circuit interruption
• High fault-clearing capability
• Enhanced electrical safety
• Improved equipment protection
• Reduced downtime risks
• Stable switching performance
• Long-term operational reliability
Mounting & Durability
• Suitable for switchboards & distribution panels
• Compatible with industrial & commercial installations
• Rugged molded case housing
• High mechanical endurance
• Low maintenance requirements
• Designed for continuous-duty operation
• Quality-engineered construction
• Suitable for demanding environments
Application Domains
• Industrial Facilities
• Manufacturing Plants
• Commercial Buildings
• OEM Equipment Panels
• Utility Installations
• Infrastructure Projects
• Electrical Distribution Systems
• Power Management Applications
Key Features
• DZ1N MCCB series
• 100A current rating
• 3 Pole configuration
• 415V AC operation
• 50kA breaking capacity
• ITRP1 trip unit
• Overload protection
• Short-circuit protection
• Industrial-grade construction
• Long service life
Applications
• Three-phase circuit protection
• Motor feeder protection
• Control panel applications
• Industrial electrical systems
• Commercial power distribution
• OEM machinery protection
• Utility installations
• Infrastructure electrical projects
FAQs
1. What is the DZ1T0100NXF1AOOOO MCCB used for?
Ans: It is used for protecting electrical circuits & equipment against overload & short-circuit faults in three-phase electrical systems.
2. What is the current rating of this MCCB?
Ans: The MCCB is rated at 100A.
3. What does 3 Pole mean?
Ans: A 3 Pole MCCB protects & switches all three phase conductors simultaneously in a three-phase electrical distribution system.
4. What is the breaking capacity of this MCCB?
Ans: It provides a 50kA short-circuit breaking capacity for safe interruption of high fault currents.
5. What is the ITRP1 trip unit?
Ans: The ITRP1 trip unit helps provide accurate overload & fault protection, improving safety & system reliability.
6. Where can this MCCB be installed?
Ans: It can be installed in switchboards, distribution panels, control panels, OEM equipment, & industrial electrical systems.
7. Is it suitable for industrial applications?
Ans: Yes, it is designed for industrial, commercial, OEM, & infrastructure electrical installations requiring reliable protection.
8. Does it require frequent maintenance?
Ans: No, its durable molded case construction & robust protection mechanism ensure long-term, low-maintenance operation under normal operating conditions.
Overview
| Rated Operational Current | 100 |
|---|---|
| Mechanical Life (No. of operating cycles) | 30000 |
| No. of Poles | 3P |
| Rated Operational voltage (Ue) | 415V AC |
| Rated Insulation Voltage Ui (V) | 800 V |
| Conformance to Standards | IEC 60947-1, EN 60947-1, IS/IEC 60947-1 IEC 60947-2, EN 60947-2, IS/IEC 60947-2 IEC 60947-3, EN 60947-3, IS/IEC 60947-3 IEC 60947-4, EN 60947-4, IS/IEC 60947-4 |
| Rated impulse withstand voltage (Uimp) | 8 kV |
| Operational Frequency (Hz) | 50/60 Hz |
| Release Type | iTRP1 |
| Rated Short Circuit Breaking capacity Icu(kA) | DZ1N MCCB 100 3P 415V AC 50kA iTRP1 50/60 Hz |
| Rated Sevice circuit breaking capacity (Ics as % of Icu) @415VAC | 50kA |
| Ambient temperature | -5°C to 55°C |
| Suitable for isolation | Yes |
| Load-line bias | No |
| Electrical Life (Operating Cycles) | 10000 |
| IP Protection | IP40 |
| Pollution Degree | III |
| Width(mm) | 75 |
| Height(mm) | 130 |
| Depth(mm) | 60 |
