Lauritz Knudsen DZ1N, MCCB, 3 Pole, 415V AC, 50kA Breaking Capacity, 16A | Thermal-Magnetic Release | IP40 Protection
Images:
Image 360:
How to video:
Further offers for this product
Incl. Tax
In Stock
No sellers found for this product.
Incl. Tax
Lauritz Knudsen DZ1N, MCCB, 3 Pole, 415V AC, 50kA Breaking Capacity, 16A | Thermal-Magnetic Release | IP40 Protection
- Description
- Specifications
- Documents
- Warranty
- Reviews
Description
About the Product
The Lauritz Knudsen DZ1N MCCB 16A 3 Pole 415V AC 50kA Thermal Magnetic is a robust molded case circuit breaker engineered to provide comprehensive protection & switching for low-voltage electrical installations. Designed to safeguard circuits against overloads & short-circuit faults, it helps protect motors, transformers, cables, switchboards, control panels, & power distribution systems from damage caused by abnormal current conditions.
Featuring a 16A rated current, 3 Pole configuration, 415V AC operating voltage, & a high 50kA short-circuit breaking capacity, this MCCB is suitable for industrial facilities, commercial buildings, OEM machinery, infrastructure projects, & utility applications where dependable protection & fault interruption are critical.
Its thermal magnetic trip mechanism combines thermal overload protection with instantaneous magnetic short-circuit protection, helping improve operational reliability, equipment safety, & system continuity.
How the Mechanism Works
The product functions by:
• Detecting overload conditions during operation
• Interrupting short-circuit fault currents rapidly
• Automatically disconnecting faulty circuits
• Protecting motors, cables, & electrical equipment
• Supporting safe & reliable power distribution
• Reducing damage caused by fault conditions
• Improving electrical system reliability
• Delivering dependable fault-clearing performance
It serves as a critical protection & switching device within low-voltage electrical systems.
Electrical Configuration
• Product Type: Molded Case Circuit Breaker (MCCB)
• Series: DZ1N
• Current Rating: 16A
• Pole Configuration: 3 Pole
• Rated Voltage: 415V AC
• Frequency: 50/60 Hz
• Breaking Capacity: 50kA
• Trip Type: Thermal Magnetic
• Application: Circuit Protection & Switching
• Suitable For: Three-Phase Electrical Systems
• Catalog Number: DZ1T0016NXC1AOOOO
Construction & Design
Designed for dependable protection:
• Thermal magnetic trip mechanism
• 16A current carrying capacity
• 3-pole switching configuration
• High 50kA fault interruption capability
• Durable molded case construction
• Reliable contact system
• Industrial-grade engineering
• Long operational lifespan
Safety & Protection
• Reliable overload protection
• Fast short-circuit interruption
• High fault-clearing capability
• Enhanced electrical safety
• Reduced equipment damage risk
• Improved system uptime
• Consistent switching performance
• Long-term operational reliability
Mounting & Durability
• Suitable for switchboards & distribution panels
• Compatible with industrial & commercial installations
• Rugged molded case housing
• High mechanical endurance
• Low maintenance requirements
• Designed for continuous-duty service
• Quality-engineered construction
• Suitable for demanding environments
Application Domains
• Industrial Facilities
• Manufacturing Plants
• Commercial Buildings
• OEM Equipment Panels
• Utility Installations
• Infrastructure Projects
• Electrical Distribution Systems
• Power Management Applications
Key Features
• DZ1N MCCB series
• 16A current rating
• 3 Pole configuration
• 415V AC operation
• 50kA breaking capacity
• Thermal magnetic protection
• Overload protection
• Short-circuit protection
• Durable molded case design
• Long service life
Applications
• Three-phase circuit protection
• Motor feeder protection
• Control panel applications
• Industrial electrical systems
• Commercial power distribution
• OEM machinery protection
• Utility installations
• Infrastructure electrical projects
FAQs
1. What is the DZ1T0016NXC1AOOOO MCCB used for?
Ans: It is used for protecting electrical circuits & connected equipment against overloads & short-circuit faults in three-phase electrical systems.
2. What is the current rating of this MCCB?
Ans: The MCCB is rated at 16A.
3. What does 3 Pole mean?
Ans: A 3 Pole MCCB protects & switches all three phase conductors simultaneously in a three-phase electrical distribution system.
4. What is the breaking capacity of this MCCB?
Ans: It provides a 50kA short-circuit breaking capacity for safe interruption of high fault currents & protection of connected equipment.
5. What is thermal magnetic protection?
Ans: Thermal magnetic protection combines thermal overload protection & instantaneous magnetic short-circuit protection for comprehensive circuit safety.
6. Where can this MCCB be installed?
Ans: It can be installed in switchboards, distribution panels, control panels, OEM equipment, commercial facilities, & industrial electrical systems.
7. Is it suitable for industrial applications?
Ans: Yes, its 50kA breaking capacity & thermal magnetic protection make it suitable for industrial, commercial, & OEM electrical installations.
8. Does it require frequent maintenance?
Ans: No, its durable molded case construction & dependable trip mechanism ensure long-term, low-maintenance operation under normal operating conditions.
Overview
| Rated Operational Current | 16 |
|---|---|
| Mechanical Life (No. of operating cycles) | 30000 |
| No. of Poles | 3P |
| Rated Operational voltage (Ue) | 415V AC |
| Rated Insulation Voltage Ui (V) | 800 V |
| Conformance to Standards | IEC 60947-1, EN 60947-1, IS/IEC 60947-1 IEC 60947-2, EN 60947-2, IS/IEC 60947-2 IEC 60947-3, EN 60947-3, IS/IEC 60947-3 IEC 60947-4, EN 60947-4, IS/IEC 60947-4 |
| Rated impulse withstand voltage (Uimp) | 8 kV |
| Operational Frequency (Hz) | 50/60 Hz |
| Release Type | TM |
| Rated Short Circuit Breaking capacity Icu(kA) | DZ1N MCCB 16 3P 415V AC 50kA Thermal Magnetic 50/60 Hz |
| Rated Sevice circuit breaking capacity (Ics as % of Icu) @415VAC | 50kA |
| Ambient temperature | -5°C to 55°C |
| Suitable for isolation | Yes |
| Load-line bias | No |
| Electrical Life (Operating Cycles) | 10000 |
| IP Protection | IP40 |
| Pollution Degree | III |
| Width(mm) | 75 |
| Height(mm) | 130 |
| Depth(mm) | 60 |
