EXORA MCB 20A TP 415V AC 10kA C Curve
In stock
SKU
BB30200C
Regular Price
₹1,450.00
Special Price
₹760.00
48% Off
( Prices are all inclusive of taxes )EXORA MCB 20A TP 415V AC 10kA C Curve
HSN Code - 85362030
HSN Code - 85362030
The price of the product is indicative and is subject to change as per batch, revision in prices at the time of delivery. Please refer to the final landing price for your reference.
Note: L&T Switchgear Business is now Lauritz Knudsen Electrical & Automation.
Some products may still be labelled as L&T Switchgear Business until existing stock lasts. The quality and service you trust remain unchanged.
CHECK DELIVERY TIME & COD AVAILABILITY
- The MCB is a vital protection device that is essential in every electrical installation to safeguard both your life and valuable property against short-circuit and overload.
-
Discount PercentageBetween 0-10 %
-
Operating Temperature Range-25°C to +70° C
-
Electrical life (Operating Cylces)20000
-
Tightening Torque4Nm
-
Termination capacity35 Sq. mm (Rigid) 25 Sq. mm (Flexible)
-
Mechanical Life (Operating Cycles)100000
-
No. of PolesTP
-
Conformance to standardsIS/IEC 60898-1
IEC 60947-2 -
Rated Insulation Voltage Ui (V)500V
-
Rated Frequency50Hz/60Hz
-
Rated Short-circuit Breaking Capacity10kA as per IS/IEC 60898-1
15kA as per IEC 60947-2 -
Rated Impulse Voltage4kV
-
Current Rating20A
-
Rated Operational voltage (Ue)415V
-
Conformance to StandardsIS/IEC 60898-1 IEC 60947-2
-
Tripping CharacteristicC Curve
-
Length(mm)74.5
-
Height(mm)87.3
-
Breadth(mm)52.5
