EXORA MCB 32A FP 415V AC 10kA C Curve

BB40320C
Be the first one to review this.

Incl. Tax

login_green To View the best prices please Sign in / Register.
loader
Loading...

Description

  • The MCB is a vital protection device that is essential in every electrical installation to safeguard both your life and valuable property against short-circuit and overload.

Product Details

Discount Percentage Between 0-10 %
Operating Temperature Range -25°C to +70° C
Electrical life (Operating Cylces) 20000
Tightening Torque 4Nm
Termination capacity 35 Sq. mm (Rigid) 25 Sq. mm (Flexible)
Mechanical Life (Operating Cycles) 100000
No. of Poles FP
Conformance to standards IS/IEC 60898-1
IEC 60947-2
Rated Insulation Voltage Ui (V) 500V
Rated Frequency 50Hz/60Hz
Rated Short-circuit Breaking Capacity 10kA as per IS/IEC 60898-1
15kA as per IEC 60947-2
Rated Impulse Voltage 4kV
Current Rating 32A
Rated Operational voltage (Ue) 415V
Conformance to Standards IS/IEC 60898-1 IEC 60947-2
Tripping Characteristic C Curve
Length(mm) 74.5
Height(mm) 87.3
Breadth(mm) 70

Related Posts

No Related Posts

Seller Information

Documents

Extended Warranty

Reviews

Write Your Own Review
This is a required field
You're reviewing: EXORA MCB 32A FP 415V AC 10kA C Curve
* Required Field
loader
Loading...

check-circle You submitted your review for moderation.

Customer Who Purchased This Product Also Bought

EXORA MCB 32A DP 240V AC 10kA C Curve
BB20320C
Price starting from
₹970.00
₹434.95
BIS Certified
EXORA MCB 32A TP 415V AC 10kA C Curve
BB30320C
Price starting from
₹1,530.00
₹686.05
BIS Certified
EXORA MCB 6A SP 240V AC 10kA C Curve
BB10060C
Price starting from
₹294.00
₹131.83
BIS Certified

The EXORA MCB 32A FP (Four Pole) 415V AC 10kA C Curve is an essential component for protecting electrical circuits from overcurrent and short circuits. Designed to automatically disconnect power when unsafe conditions are detected, this MCB safeguards electrical systems by preventing damage and potential hazards.

Features and Benefits

Technical Specifications

Applications

The EXORA MCB 32A FP is ideal for a range of applications, including residential electrical systems, industrial machinery, and commercial buildings. It is particularly effective in circuits that require robust protection against overloads and short circuits, ensuring reliable operation and enhanced safety.

Installation and Usage

Installation involves connecting the MCB to the electrical panel following standard procedures. Ensure that all safety precautions are observed during installation, including disconnecting power before fitting the MCB.

Price and Availability

Contact our sales team for the most competitive MCB 32 Amp 4 pole price if you wish to make a bulk purchase. We also offer discounts at 4 pole MCB 32 Amp price.
