Lauritz Knudsen EXORA, MCB, 1 Pole, 250V DC, 10kA, C Curve, 32A
Images:
Image 360:
How to video:
Further offers for this product
Incl. Tax
In Stock
No sellers found for this product.
Incl. Tax
Lauritz Knudsen EXORA, MCB, 1 Pole, 250V DC, 10kA, C Curve, 32A
- Description
- Specifications
- Documents
- Warranty
- Reviews
Description
About the Product
Exora MCB 32A SP 250V DC 10kA C Curve is a single pole miniature circuit breaker designed for high-load DC applications requiring enhanced fault interruption capability. It ensures reliable protection against overload and short circuit faults in demanding DC electrical systems.
How the Mechanism Works
The breaker operates using a thermal magnetic protection mechanism:
- The thermal element responds to sustained overload conditions and provides time-delayed tripping to protect cables and connected systems from overheating.
- The magnetic element ensures instantaneous tripping during short circuit faults, enabling quick fault isolation and minimizing damage.
The C curve tripping characteristic supports moderate inrush currents, ensuring stable operation without nuisance tripping.
Electrical Configuration
This is a single pole (SP) MCB rated at:
- Current: 32A
- Voltage: 250V DC
- Breaking capacity: 10kA
The 10kA breaking capacity ensures safe interruption of higher fault currents, making this breaker suitable for installations with elevated fault levels.
Safety & Protection
The breaker provides protection against:
- Overload conditions
- Short circuit faults
Its high 10kA fault interruption capability enhances electrical safety by protecting cables, devices, and infrastructure in heavy-load DC systems.
Mounting and Durability
Designed for DIN rail mounting, the breaker can be easily installed in DC distribution panels and control systems. Its compact and robust construction ensures long service life and reliable performance in industrial and commercial applications.
Application Domains
Suitable for a wide range of DC systems including:
- Solar photovoltaic (PV) systems
- Battery energy storage systems (BESS)
- DC distribution panels
- Industrial automation systems
- Telecom and instrumentation circuits
Key Features
- Rated current: 32A
- Single pole (SP) configuration
- Rated voltage: 250V DC
- Breaking capacity: 10kA
- C curve tripping characteristic
- Thermal magnetic protection mechanism
- High fault interruption capability
- DIN rail mounting compatible
- Suitable for DC applications
- Compact and durable design
Applications
- Solar PV systems
- Battery storage systems
- DC control panels
- Industrial automation systems
- Telecom installations
FAQs
What is a 32A 250V DC MCB used for?
Ans: It is used to protect high-load DC circuits from overload and short circuit faults with enhanced safety.
What is the advantage of 10kA breaking capacity?
Ans: It allows safe interruption of higher fault currents, making it suitable for demanding DC installations.
What is C curve in DC MCB?
Ans: C curve allows moderate inrush current, suitable for general-purpose DC applications.
Why use 250V DC MCB?
Ans: It is designed for higher voltage DC systems such as solar arrays and battery storage systems.
Where is it typically used?
Ans: It is commonly used in solar systems, battery installations, telecom systems, and industrial control panels.
How is it installed?
Ans: It is mounted on a DIN rail inside DC distribution boards or control panels.
Overview
| Discount Percentage | Between 0-10 % |
|---|---|
| Operating Temperature Range | -25°C to +70°C |
| Electrical life (Operating Cylces) | 3000 |
| Tightening Torque | 4Nm |
| Termination capacity | 35 Sq. mm (Rigid) 25 Sq. mm (Flexible) |
| Mechanical Life (Operating Cycles) | 100000 |
| No. of Poles | SP |
| Conformance to standards | IEC 60947-2 |
| Rated Insulation Voltage Ui (V) | 500V |
| Rated Short-circuit Breaking Capacity | 10kA |
| Rated Impulse Voltage | 4kV |
| Current Rating | 32A |
| Rated Operational voltage (Ue) | 250V |
| Conformance to Standards | IEC 60947-2 |
| Tripping Characteristic | C Curve |
| Length(mm) | 74.5 |
| Height(mm) | 87.3 |
| Breadth(mm) | 17.5 |
Warranty
- All products listed in the price list are covered by a warranty against manufacturing defects for a period of 18* months from the date of purchase.
- For Lauritz Knudsen MCBs & Isolators mounted inside Lauritz Knudsen Distribution Boards, an extended warranty of 5 years is provided.
- In the event of a defect due to faulty workmanship or other associated reasons, the manufacturer will, at its discretion, remedy the defect or replace the faulty parts or the entire product as soon as possible, free of cost.
- This warranty is subject to proper usage and efficient maintenance and does not cover defects arising from fire, accidents, inefficient maintenance, faulty operation, or deliberate or accidental damage.
- The warranty does not cover damage to power electronic components such as thyristors & IGBTs, which primarily fail due to over-temperature or over-voltage. Users must take adequate precautions to eliminate such conditions.
- The manufacturer shall not be responsible or liable for any special, incidental, social, or consequential losses (including loss of profits), punitive damages, injury, or damages of any kind solely attributable to defect or failure of its products.
- The manufacturer shall not be liable in any manner for issues related to or failure in the performance of any other equipment to which the product is connected.
