EXORA RCCB 100A FP 415V AC 300mA
In stock
SKU
BG410030
Regular Price
Price:
₹8,490.00
Special Price
Price:
₹4,207.64
50% Off
( Prices are all inclusive of taxes )
EXORA RCCB 100A FP 415V AC 300mA
HSN Code - 85362040
HSN Code - 85362040
The price of the product is indicative and is subject to change as per batch, revision in prices at the time of delivery. Please refer to the final landing price for your reference.
Note: L&T Switchgear is now Lauritz Knudsen Electrical & Automation.
Some products may still be labelled as L&T SWITCHGEAR until existing stock lasts. The quality and service you trust remain unchanged.
CHECK DELIVERY TIME & COD AVAILABILITY
No sellers found for this product.
Residual Current Circuit Breakers provide protection against earth leakage faultThey ensure safety of human life in case of earth leakage fault and protection against electric shock.
| Discount Percentage | Between 0-10 % |
| Operating Temperature Range | -5°C to +55°C |
| Electrical life (Operating Cylces) | 10000 |
| Tightening Torque | 4Nm |
| Termination capacity | 50 Sq. mm (Rigid) 35 Sq. mm (Flexible) |
| Mechanical Life (Operating Cycles) | 20000 |
| No. of Poles | FP |
| Conformance to standards |
IS 12640-1 IEC 61008-1 |
| Rated Insulation Voltage Ui (V) | 500V |
| Rated Frequency | 50Hz |
| Rated Residual Making & Breaking capacity | 1 kA |
| Rated Impulse Voltage | 4kV |
| Rated Conditional SC Current | 10 kA |
| Current Rating | 100A |
| Rated Operational voltage (Ue) | 415V |
| Conformance to Standards | IS 12640-1 IEC 61008-1 |
| Sensitivity | 300mA |
| Length(mm) | 77.1 |
| Height(mm) | 83 |
| Breadth(mm) | 71 |
