EXORA RCCB 40A FP 415V AC 30mA
In stock
SKU
BG404003
Regular Price
₹4,275.00
Special Price
₹3,531.15
17% Off
( Prices are all inclusive of taxes )EXORA RCCB 40A FP 415V AC 30mA
HSN Code - 85362040
HSN Code - 85362040
The price of the product is indicative and is subject to change as per batch, revision in prices at the time of delivery. Please refer to the final landing price for your reference.
Note: L&T Switchgear Business is now Lauritz Knudsen Electrical & Automation.
Some products may still be labelled as L&T Switchgear Business until existing stock lasts. The quality and service you trust remain unchanged.
CHECK DELIVERY TIME & COD AVAILABILITY
Residual Current Circuit Breakers provide protection against earth leakage faultThey ensure safety of human life in case of earth leakage fault and protection against electric shock.
-
Discount PercentageBetween 0-10 %
-
Operating Temperature Range-5°C to +55°C
-
Electrical life (Operating Cylces)10000
-
Tightening Torque4Nm
-
Termination capacity50 Sq. mm (Rigid) 35 Sq. mm (Flexible)
-
Mechanical Life (Operating Cycles)20000
-
No. of PolesFP
-
Conformance to standardsIS 12640-1
IEC 61008-1 -
Rated Insulation Voltage Ui (V)500V
-
Rated Frequency50Hz
-
Rated Residual Making & Breaking capacity1 kA
-
Rated Impulse Voltage4kV
-
Rated Conditional SC Current10 kA
-
Current Rating40A
-
Rated Operational voltage (Ue)415V
-
Conformance to StandardsIS 12640-1 IEC 61008-1
-
Sensitivity30mA
-
Length(mm)77.1
-
Height(mm)83
-
Breadth(mm)71
