EXORA RCCB 63A DP 240V AC 30mA

In stock
SKU
BG206303
Regular Price ₹4,485.00 Special Price ₹3,704.61
17% Off ( Prices are all inclusive of taxes )
Be the first to review this product
Add to Compare
EXORA RCCB 63A DP 240V AC 30mA

HSN Code - 85362040

The price of the product is indicative and is subject to change as per batch, revision in prices at the time of delivery. Please refer to the final landing price for your reference.

Note: L&T Switchgear Business is now Lauritz Knudsen Electrical & Automation.
Some products may still be labelled as L&T Switchgear Business until existing stock lasts. The quality and service you trust remain unchanged.

CHECK DELIVERY TIME & COD AVAILABILITY

Residual Current Circuit Breakers provide protection against earth leakage fault
  • They ensure safety of human life in case of earth leakage fault and protection against electric shock.
    • Technical Specifications
    • Discount Percentage
      Between 0-10 %
    • Operating Temperature Range
      -5°C to +55°C
    • Electrical life (Operating Cylces)
      10000
    • Tightening Torque
      4Nm
    • Termination capacity
      50 Sq. mm (Rigid) 35 Sq. mm (Flexible)
    • Mechanical Life (Operating Cycles)
      20000
    • No. of Poles
      DP
    • Conformance to standards
      IS 12640-1
      IEC 61008-1
    • Rated Insulation Voltage Ui (V)
      500V
    • Rated Frequency
      50Hz
    • Rated Residual Making & Breaking capacity
      1 kA
    • Rated Impulse Voltage
      4kV
    • Rated Conditional SC Current
      10 kA
    • Current Rating
      63A
    • Rated Operational voltage (Ue)
      240V
    • Conformance to Standards
      IS 12640-1 IEC 61008-1
    • Sensitivity
      30mA
    • Length(mm)
      77.1
    • Height(mm)
      83
    • Breadth(mm)
      35
