FN SDF 125A 2P 415V AC Open Execution DIN Type Fuse 50/60 Hz
In stock
SKU
ST35087OOOO
Regular Price
₹7,730.00
Special Price
₹6,384.98
17% Off
( Prices are all inclusive of taxes )FN SDF 125A 2P 415V AC Open Execution DIN Type Fuse 50/60 Hz
HSN Code - 85371000
HSN Code - 85371000
The price of the product is indicative and is subject to change as per batch, revision in prices at the time of delivery. Please refer to the final landing price for your reference.
Note: L&T Switchgear Business is now Lauritz Knudsen Electrical & Automation.
Some products may still be labelled as L&T Switchgear Business until existing stock lasts. The quality and service you trust remain unchanged.
CHECK DELIVERY TIME & COD AVAILABILITY
FN SDFs come with the following safety features as a standard offering:
-Terminal Shrouds on both line and load side
-Phase barriers
-High clearances and creepage distances
-High ground clearance
Offering:
-Range: 32A to 800A
-Available in open execution and SS enclosure variants
-Versions: Suitable for DIN type and Bolted type fuses
-HE SDF version for harsh sulphurous environment
-Configurations: 2P, TPN, 4P(100% rated, Switched neutral)
Salient Features:
-AC-23A utilization category for entire range
-Quick-make /Quick-break mechanism
-Quad break contact system : Better arc quenching and higher electrical life of contacts
-Telescopic Shaft: Step-less depth adjustment
-Suitable for Aluminum termination
-Ample space for termination in spacious SS enclosure version
-No separate cable gland boxes required Clear ON/OFF indications
-Door interlocking in ON position with defeat feature
-Terminal Shrouds on both line and load side
-Phase barriers
-High clearances and creepage distances
-High ground clearance
Offering:
-Range: 32A to 800A
-Available in open execution and SS enclosure variants
-Versions: Suitable for DIN type and Bolted type fuses
-HE SDF version for harsh sulphurous environment
-Configurations: 2P, TPN, 4P(100% rated, Switched neutral)
Salient Features:
-AC-23A utilization category for entire range
-Quick-make /Quick-break mechanism
-Quad break contact system : Better arc quenching and higher electrical life of contacts
-Telescopic Shaft: Step-less depth adjustment
-Suitable for Aluminum termination
-Ample space for termination in spacious SS enclosure version
-No separate cable gland boxes required Clear ON/OFF indications
-Door interlocking in ON position with defeat feature
-
Rated Operational Current (A)125A
-
Conformance to StandardsIS/IEC 60947-3, EN 60947-3
-
Fuse TypeDIN /Knife-edge
-
Utilization CategoryAC-23A
-
Rated operational voltage (Ue)415V
-
Operating Frequency(Hz)50/60
-
Mechanical Life (No. of operating cycles)15000
-
Rated Insulation Voltage Ui (V)690V
-
Rated Breaking Capacity@AC-23A (A)1000
-
Rated Making Capacity@AC-23A (A)1250
-
VersionOpen Execution
-
No. of Poles2P
-
Maximum Al termination (sq.mm)95
-
Mounting positionsAll Orientations
-
Standard AccessoriesTerminal Shrouds, Phase Barriers, Extended handle with shaft
-
Pollution Degree3
-
Discount PercentageBetween 0-10 %
