MO0 Control Contactor 4A 4P 415V AC 3NO+1NC AC-15 24V AC Coil 50/60 Hz

CS91624GOOO
Be the first one to review this.

Incl. Tax

login_green To View the best prices please Sign in / Register.
loader
Loading...

Description

  • MO0 AC control contactors are 4 pole block type contactors.
  • These contactors are used for switching auxiliary circuits and control circuits.
  • The number of contacts can be extended up to 8 nos with the help of addon blocks.
  • Control circuit : AC operated and suitable for 50/60 Hz.
  • DIN rail mounting facility available.
  • Wide range of accessories and spares are available

Product Details

Ambient temperature -5 to 55 degree C
Mechanical Life (No. of operating cycles) 7200 Operations/Hr
Rated impulse withstand voltage (Uimp) 8kV
Rated Insulation Voltage Ui (V) 1000V
Conformance to Standards IS/IEC 6094751, IEC 6094751, EN 6094751
Coil Voltage 24 V AC
Rated operational current at 415V 4A (AC15)
Discount Percentage Between 0-10 %
No. of Poles 3NO+1NC
Height(mm) 86.5
Width(mm) 45
Depth(mm) 89
Coil Operating band %Uc (Pick up) 65 - 110 %
Mechanical Life 10 million
Coil Operating band %Uc (Drop off) 30 - 55 %
Pick up VA consumption 68VA
Hold on VA consumption 9VA
