Lauritz Knudsen Standard Duty Box Capacitor, 1 kVAr, 440V AC | Inbuilt Over Pressure Disconnector (OPD) | 150% continuous current carrying capacity | Long Life
SKU :
LTBCF301B2
Unfortunately this product is not available at this moment
Notify me when this product is available
Loading...
Further offers for this product
LTBCF301B2
Lauritz Knudsen Standard Duty Box Capacitor, 1 kVAr, 440V AC | Inbuilt Over Pressure Disconnector (OPD) | 150% continuous current carrying capacity | Long Life
Further Offers for this product:
Shipping options & Estimated costs
Delivery by 5-7 business day
Incl. Tax
Free shipping on orders above ₹1000
In Stock
A backorder means the item you want is currently not in stock, but we’re still allowing you to place an order for it. we will ship it to you within the estimated shipping time.
Shipping options
Delivery by 5-7 business day
No sellers found for this product.
₹310.00
₹256.06
Incl. Tax
To View the best prices please Log In / Register
Estimated delivery:
Backorder
A backorder means the item you want is currently not in stock, but we’re still allowing you to place an order for it. we will ship it to you within the estimated shipping time.
Estimated delivery:
Out of stock
Lauritz Knudsen Standard Duty Box Capacitor, 1 kVAr, 440V AC | Inbuilt Over Pressure Disconnector (OPD) | 150% continuous current carrying capacity | Long Life
₹310.00
₹256.06
- Description
- Specifications
- Documents
- Warranty
- Reviews
Description
- Lauritz Knudsen Standard Duty Capacitors are Metalized polypropylene capacitors with stacked winding and Non-PCB biodegradable resin impregnation.
- These capacitors are self healing type with safety features such as Over Pressure Disconnection and Finger-proof termination.
- These can be used to provide effective Power Factor correction in Small scale industrial applications.
Overview
| Over Voltage Withstand Ability | 10% (8h/24h), 15% (30m/24h), 20% (5m/24h), 30% (1m/24h) |
|---|---|
| Peak Inrush Current Withstand Ability | 200 × In |
| Length(mm) | 108 |
| Height(mm) | 112 |
| Breadth(mm) | 38 |
| Total Operating Losses | 0.45 Watts / kVAr |
| Over Current Withstand Ability | 1.5 × In |
| Switching Operation Cycles Per Year | 5000 |
| Operating Life Under Standard Conditions | 100000 hours |
| Ambient Temperature Range | -25 ˚C to 55 ˚C |
| Discount Percentage | Between 0-10 % |
Documents
Warranty
1. All products listed in the price list are covered by a warranty against manufacturing defects for a period of 18* months from the date of purchase.
View All
- All products listed in the price list are covered by a warranty against manufacturing defects for a period of 18* months from the date of purchase.
- For Lauritz Knudsen MCBs & Isolators mounted inside Lauritz Knudsen Distribution Boards, an extended warranty of 5 years is provided.
- In the event of a defect due to faulty workmanship or other associated reasons, the manufacturer will, at its discretion, remedy the defect or replace the faulty parts or the entire product as soon as possible, free of cost.
- This warranty is subject to proper usage and efficient maintenance and does not cover defects arising from fire, accidents, inefficient maintenance, faulty operation, or deliberate or accidental damage.
- The warranty does not cover damage to power electronic components such as thyristors & IGBTs, which primarily fail due to over-temperature or over-voltage. Users must take adequate precautions to eliminate such conditions.
- The manufacturer shall not be responsible or liable for any special, incidental, social, or consequential losses (including loss of profits), punitive damages, injury, or damages of any kind solely attributable to defect or failure of its products.
- The manufacturer shall not be liable in any manner for issues related to or failure in the performance of any other equipment to which the product is connected.
Reviews
Write Your Own Review
Only registered users can write reviews. Please Sign in or create an account
