Tripper Isolator 40A TP 415V AC

In stock
SKU
BE304000
₹810.00
( Prices are all inclusive of taxes )
Be the first to review this product
Add to Compare
Tripper Isolator 40A TP 415V AC

HSN Code - 85363000

The price of the product is indicative and is subject to change as per batch, revision in prices at the time of delivery. Please refer to the final landing price for your reference.

Note: L&T Switchgear is now Lauritz Knudsen Electrical & Automation.
Some products may still be labelled as L&T SWITCHGEAR until existing stock lasts. The quality and service you trust remain unchanged.

CHECK DELIVERY TIME & COD AVAILABILITY

Isolators are used in electrical installations to make, carry and break circuit current
  • The Isolator ensures that the circuit remains completely isolated
    • Technical Specifications
    • Discount Percentage
      Between 0-10 %
    • Operating Temperature Range
      -5°C to +50°C
    • Electrical life (Operating Cylces)
      10000
    • Tightening Torque
      4Nm
    • Termination capacity
      35 Sq. mm (Rigid) 25 Sq. mm (Flexible)
    • Mechanical Life (Operating Cycles)
      100000
    • No. of Poles
      TP
    • Rated Insulation Voltage Ui (V)
      500V
    • Rated Frequency
      50Hz
    • Rated Impulse Voltage
      4kV
    • Current Rating
      40A
    • Rated operational voltage (Ue)
      415V
    • Conformance to Standards
      IEC 60947-3
    • Length(mm)
      74.5
    • Height(mm)
      87.3
    • Breadth(mm)
      52.5
