Tripper RCBO(EL+MCB) 63A FP 415V AC 6kA 30mA C Curve

In stock
SKU
CB90002OOHO
Regular Price ₹5,970.00 Special Price ₹4,477.50
25% Off ( Prices are all inclusive of taxes )
Be the first to review this product
Add to Compare
Tripper RCBO(EL+MCB) 63A FP 415V AC 6kA 30mA C Curve

HSN Code - 85362090

The price of the product is indicative and is subject to change as per batch, revision in prices at the time of delivery. Please refer to the final landing price for your reference.

Note: L&T Switchgear Business is now Lauritz Knudsen Electrical & Automation.
Some products may still be labelled as L&T Switchgear Business until existing stock lasts. The quality and service you trust remain unchanged.

CHECK DELIVERY TIME & COD AVAILABILITY

  • RCBOs provides protection from overload, short-circuit and earth leakage
Technical Specifications
  • Discount Percentage
    Between 0-10 %
  • Operating Temperature Range
    -5°C to +40°C
  • Electrical life (Operating Cylces)
    10000
  • Tightening Torque
    3Nm
  • Termination capacity
    25 Sq. mm (Rigid)
  • Mechanical Life (Operating Cycles)
    20000
  • No. of Poles
    FP
  • Rated Insulation Voltage Ui (V)
    500V
  • Rated Frequency
    50Hz/60Hz
  • Rated Short-circuit Breaking Capacity
    6kA
  • Rated Impulse Voltage
    4kV
  • Current Rating
    63A
  • Rated operational voltage (Ue)
    415V
  • Conformance to Standards
    IEC 61009-1
  • Tripping Characteristic
    C Curve
  • Sensitivity
    30mA
  • Length(mm)
    73.5
  • Height(mm)
    82.5
  • Breadth(mm)
    105
