The Ultimate Guide to 3-Phase Induction Motors!

The 3 phase induction motors are some of the most widely used commodities in the electrical industry. They are utilised as the framework in many operations, including industrial production and household utilities. If you wish to know about the importance of 3-phase induction motors, then you are at the right place. In this guide, we will explore types of 3 phase induction motor, working principles of 3-phase induction motors, areas of application of 3-phase induction motors, advantages of using the 3-phase induction motors and finally, disadvantages of using 3-phase induction motors. We will also look at how they run and why they are preferred in different industries.

What is 3 Phase Induction Motor?

In its simplest context, a 3-phase induction motor is an electrical device that converts electrical power to mechanical power. Like most machines, it is based on the principle of electromagnetic attraction and repulsion, which pitch the machine into motion. Distinct from single-phase induction motors, three-phase AC induction motors require three separate phase currents, which are displaced phase by phase by 120°. Thus, a revolving magnetic field is established that causes the motor’s rotor to experience mechanical motion.

Types of 3 Phase Induction Motor

There are primarily two types of 3 phase induction motor.

• Squirrel Cage Induction Motor: This is the most common type, also called squirrel cage induction motor, because of its rotor shape. It is simple and, at the same time, reliable and cheap compared to other types of design. Squirrel cage motor is highly efficient and low on maintenance; thus, it is suitable for the majority of industrial applications.
• Wound Rotor Induction Motor: Unlike the squirrel cage type, it has a rotor winding. It is handy to use where variable speeds are required. The wound rotor motor makes it easier to start and control the motor than the squirrel cage motor. It is usually more expensive and intricate than the squirrel cage motor.

Working Principle of 3 Phase Induction Motor

The operation of 3 phase induction motor is grounded on the principle of Faraday’s Electromagnetic Induction Postulate‎. Here’s a step-by-step explanation:

• Creation of Rotating Magnetic Field: The Stator consists of coils or groups of coils, and when a 3-phase current flows through the windings, it develops a rotating magnetic field. This field rotates at that speed, which is synchronous with the supply frequency and number of poles in the motor.
• Induction in the Rotor: It causes the production of a current in the rotor conductors, depending on the form of the rotor, which is either the squirrel cage or wound rotor. As per Lenz’s Law, the stator current generates its own magnetic field in the rotor, which opposes the stator magnetic field.
• Generation of Torque: The magnetic field of the stator rotates and interacts with the position of the rotor’s magnetic field to develop torque. This torque results in the rotation of the rotor as it develops mechanical movement.
• Slip and Speed: It is about 5-10% lower than the synchronous speed of the rotating magnetic field. This is the difference in the speeds, which are referred to as “slip,” that generate torque.

Application of 3 Phase Induction Motor

The versatility of 3-phase induction motors makes them suitable for a wide range of applications:

• Industrial Drives: It is commonly used in industries for conveyors, pumps, fans, and compressors.
• HVAC Systems: These motors are applied to the air conditioning equipment as well as large fans.
• Machine Tools: They are used in milling machines, lathes, and other massive plants, as well as complicated equipment.
• Pumps and Compressors: In water supply systems, in agriculture, and in numerous industrial processes such as the pumping of water & gases, 3-phase induction motors are employed.
• Home Appliances: Some of the residential applications include washing machines and large refrigerators.

Advantages of 3 Phase Induction Motor

Below are the most significant advantages of 3 phase induction motor.

• High Efficiency: They are more efficient than single-phase motors, especially in large sizes.
• Robust and Reliable: As designed and constructed, they are robust and can cope with extreme working environments.
• Low Maintenance: Due to their fewer components involving more flexibility, these motors are easy to maintain.
• Smooth Operation: The three-phase supply means that there is a constant supply of electricity, and this gives a steady flow that does not cause vibrations and, thus, makes less noise.
• Cost-Effective: Compared to other motors, the price of 3-phase induction motors is relatively low for the output of power.

Disadvantages of 3 Phase Induction Motor

Despite their advantages, 3-phase induction motors have some drawbacks:

• Complexity in Control: If high accuracy is needed for speed and torque, advanced control and protection are usually necessary.
• Initial Cost: The initial cost can be greater than that of single-phase motors, particularly in low-voltage applications.
• Size and Weight: They are found to be heavier and larger than single-phase motors, which may be a factor to be considered, especially when space is an issue.
• Power Supply Requirement: They need a three-phase supply, which may not be common in certain areas, particularly in residential areas.

Operation of 3 Phase Induction Motor

The operation of a 3-phase induction motor involves several key aspects:

• Starting Mechanisms: The following methods are used to regulate the in-rush current during the starting of the motor: (dol) direct online starting, star-delta starting, and autotransformer starting.
• Speed Control: Synchronous speed is dependent on the supply frequency and the number of poles, while speed regulation can be achieved through a variety of techniques, such as voltage XOR change in supply frequency or the use of VFDs.
• Protection: Overload protection is achieved by using overload relays or thermal protectors, while the circuit breaker is used in case of electrical faults affecting the motor.
• Maintenance: Doing maintenance checks periodically, for example, checking the insulation resistance, vibration and proper lubrication, is critical if the lifespan of the motors is to be achieved.

Also Read: Unveiling Power Of the Star-Delta Starter: Functions, Types and Use

Conclusion

3-phase induction motors stand as one of the great inventions of human beings in the field of electrical and mechanical industries. As a result of their flexibility, they prove to be valuable counterparts in both commercial and domestic usage as they guarantee a consistent and stable performance in various applications. Therefore, having the knowledge of what a 3-phase induction motor is, its various types, working principle and lastly, the pros and cons act as a good grounding in order to harness the potential of these motors.
