Description
About the Product
The Lauritz Knudsen CM99804OOOO is a Combined Auxiliary Contact & Trip Alarm Contact Module specifically designed for compatibility with DU400N, DN2, DN3B, & DN3 series Moulded Case Circuit Breakers (MCCBs). This advanced accessory integrates two essential monitoring functions into a single compact module, providing comprehensive visibility of both MCCB operating status & fault conditions. It is ideally suited for high-capacity power distribution systems where accurate monitoring, automation integration, & rapid fault detection are critical for operational safety & reliability.
The module combines one Auxiliary Contact (1C/O) & one Trip Alarm Contact (1C/O), allowing independent monitoring of breaker status & fault events. The auxiliary contact changes state according to the MCCB ON/OFF position, providing real-time operational feedback. The trip alarm contact activates only when the MCCB trips due to overload, short-circuit, or other fault conditions, enabling clear differentiation between normal switching operations & protection-related trips.
This dual-function capability significantly improves system diagnostics & operational awareness by providing two separate signals from a single accessory. Operators & automation systems can quickly determine whether the breaker has been manually switched or has disconnected due to an electrical fault, reducing troubleshooting time & improving response efficiency.
Each contact is configured as a 1 Changeover (1C/O) contact with Common (C), Normally Open (NO), & Normally Closed (NC) terminals. This flexible arrangement enables seamless integration with PLCs, SCADA systems, Building Management Systems (BMS), alarm circuits, annunciation panels, & remote monitoring platforms.
The module features a right-side mounting configuration, ensuring proper fitment with compatible MCCB series while allowing flexible panel design & wiring arrangements. Its compact construction simplifies installation & minimizes space requirements within switchgear & control panels.
Designed for demanding industrial, infrastructure, & utility applications, the accessory operates independently of the MCCB protection mechanism & does not affect breaker performance. It provides reliable long-term operation & accurate signaling while maintaining the full protective functionality of the MCCB.
This combined auxiliary & trip alarm contact module is the ideal solution for installations requiring comprehensive breaker status monitoring, fault indication, centralized supervision, & advanced automation integration.
How the Mechanism Works
The accessory functions by:
• Monitoring the MCCB ON/OFF operating position
• Providing auxiliary contact feedback during normal switching operations
• Monitoring the MCCB trip mechanism continuously
• Detecting overload & short-circuit fault trips
• Activating trip alarm signaling during fault conditions
• Allowing clear distinction between normal operation & fault events
• Providing independent status & fault indication outputs
• Supporting remote monitoring & automation systems
• Improving electrical system diagnostics & troubleshooting
• Enhancing operational safety & response capability
It serves as a dual-function monitoring accessory that provides both MCCB status indication & dedicated fault signaling.
Electrical Configuration
• Product Type: Combined Auxiliary & Trip Alarm Contact Module
• Model: CM99804OOOO
• Auxiliary Contact Configuration: 1 Changeover (1C/O)
• Trip Alarm Contact Configuration: 1 Changeover (1C/O)
• Contact Arrangement: Common (C), Normally Open (NO), Normally Closed (NC)
• Mounting Position: Right Side
• Compatible MCCB Series:
• DU400N Series
• DN2 Series
• DN3B Series
• DN3 Series
• Function: Status Indication & Fault Monitoring
• Application: Monitoring, Signaling, & Automation Integration
• System Integration: PLC, BMS, SCADA, Alarm Systems
• Primary Purpose: Combined Operational & Fault Feedback
Construction & Design
Designed for reliability & seamless integration:
• Compact dual-function module design
• Right-side mounting configuration
• Integrated auxiliary & trip alarm contacts
• Precision-engineered contact mechanism
• Durable switching components
• Reliable electrical signaling performance
• Secure MCCB integration design
• Heavy-duty application compatibility
• Long operational service life
• Low maintenance requirements
Safety & Protection
• Real-time MCCB ON/OFF indication
• Immediate fault trip indication
• Clear distinction between switching & fault events
• Improved operational visibility
• Enhanced fault diagnostics
• Faster maintenance response
• Reliable alarm activation capability
• Improved electrical safety management
• Supports centralized monitoring systems
• Reduces downtime & troubleshooting efforts
Mounting & Durability
• Easy installation on compatible MCCBs
• Right-side mounting flexibility
• Supports PLC integration
• Compatible with Building Management Systems (BMS)
• Suitable for SCADA & monitoring systems
• Supports alarm & annunciation systems
• Saves panel space by combining two functions
• Reduces wiring complexity
• Suitable for retrofit & new installations
• Reliable long-term performance
Application Domains
• Industrial Power Distribution Systems
• High-Capacity Switchgear Panels
• Infrastructure & Utility Installations
• Building Management Systems (BMS)
• PLC & Automation Systems
• Alarm & Annunciation Systems
• Fault Monitoring & Safety-Critical Installations
• SCADA Monitoring Platforms
• Critical Power Distribution Networks
• Electrical Protection & Control Systems
Key Features
• Combined Auxiliary + Trip Alarm Contact module
• Configuration: 1C/O (Auxiliary) + 1C/O (Trip Alarm)
• Provides ON/OFF status indication
• Provides fault/trip indication
• Right-side mounting configuration
• Compatible with DU400N series
• Compatible with DN2 series
• Compatible with DN3B series
• Compatible with DN3 series
• Dual independent outputs with NO/NC flexibility
• Enables integration with PLC, BMS, & alarm systems
• Distinguishes between normal operation & fault conditions
• Ideal for high-capacity MCCB applications
• Compact, reliable, & easy-to-install design
Applications
• Industrial power distribution systems
• High-capacity switchgear panels
• Infrastructure & utility installations
• Building Management Systems (BMS)
• PLC & automation systems
• Alarm & annunciation systems
• Fault monitoring & safety-critical installations
• SCADA monitoring systems
• Electrical protection applications
• Critical power distribution installations
FAQs
1. What is the purpose of this combined module?
Ans: It provides both MCCB ON/OFF status indication & fault trip indication in a single compact accessory module.
2. What does 1C/O + 1C/O mean?
Ans: It means the module contains two separate changeover contacts: one auxiliary contact for operational status indication & one trip alarm contact for fault indication.
3. How is this better than separate modules?
Ans: It combines both monitoring functions into one unit, reducing panel space requirements, simplifying installation, & minimizing wiring complexity.
4. What does “Right” indicate?
Ans: It refers to the right-side mounting position of the module on the MCCB.
5. Which MCCBs is this compatible with?
Ans: It is compatible with DU400N, DN2, DN3B, & DN3 series MCCBs.
6. Does it affect MCCB protection?
Ans: No, it only provides signaling & monitoring functions & does not interfere with the MCCB's protection, tripping, or operating characteristics.
7. Can it be integrated with PLCs & BMS systems?
Ans: Yes, it is fully compatible with PLCs, SCADA systems, Building Management Systems (BMS), alarm circuits, & remote monitoring platforms.
8. Why is combined status & fault monitoring important?
Ans: Combined monitoring helps operators quickly determine whether a breaker has been intentionally switched OFF or has tripped because of a fault, improving diagnostics, reducing downtime, & enhancing operational safety.
Overview
| Other Specification 1 | Auxiliary+Trip Alarm Contact |
|---|---|
| Other Specification 2 | (1C/O+1C/O Right) |
| Discount Percentage | Between 0-10 % |
