Lauritz Knudsen EXORA, Distribution Board (DB) 7 Segment, Double Door, IP43 MCCB I/C, 4 Way
- Description
- Specifications
- Warranty
- Reviews
Description
About the Product
Exora DB 7 Segment 4 Way Double Door IP43 Modular with MCCB is a compact modular distribution board designed to accommodate up to 4 outgoing ways for electrical protection devices such as MCBs, RCCBs, and RCBOs. It comes equipped with a built-in MCCB incomer, providing superior protection against overload and short circuit faults. The double door construction and IP43 rating ensure enhanced safety and durability in semi-protected environments.
How the Mechanism Works
This distribution board functions as a structured single-phase electrical system:
- The MCCB incomer acts as the main protection and isolation device
- Incoming power is distributed to multiple outgoing circuits through modular devices
- Ensures safe and organized routing of electrical connections
The double door design provides controlled access while maintaining protection of internal components.
Construction and Configuration
- System type: 7 segment modular distribution board
- Way / capacity: 4 way
- Incomer: MCCB
- Door type: Double door
- Protection rating: IP43
- Mounting type: Surface or wall mount
Standard internal configuration includes:
- DIN rail mounting system for modular devices
- Neutral and earth bars
- Compact internal wiring space
- Circuit identification and labeling provision
- Provision for cable entry and management
Safety & Protection
- MCCB incomer provides overload and short circuit protection
- IP43 protection against dust and water splashes
- Double door design enhances safety and access control
- Prevents accidental contact with live components
- Organized layout minimizes wiring errors
Mounting and Durability
- Designed for wall or surface mounting
- Compact yet durable enclosure design
- Powder-coated finish for long-lasting performance
- Suitable for residential and commercial environments
Application Domains
- Residential electrical distribution systems
- Small commercial installations
- Apartments and housing units
- Lighting and power circuit panels
- Compact protected sub-distribution boards
Key Features
- 7 segment modular configuration
- 4 way circuit capacity
- Integrated MCCB incomer for enhanced protection
- Double door enclosure for improved safety
- IP43 protection against dust and water splashes
- Compact and efficient design
- DIN rail compatible
- Easy installation and maintenance
- Durable construction
- Wall mounting compatible
Applications
- Homes and apartments
- Small offices and commercial units
- Electrical control panels
- Lighting circuit distribution
- Low-load protected systems
FAQs
What is the function of the MCCB in this DB?
Ans: The MCCB acts as the main incomer, providing protection against overload and short circuit conditions.
What is a 7 segment DB enclosure?
Ans: It is a modular distribution board designed for compact and efficient installation of electrical protection devices.
What does 4 way mean?
Ans: It refers to the number of outgoing circuits supported by the distribution board.
What is the advantage of a double door design?
Ans: It improves safety by providing controlled access and additional protection for internal components.
What does IP43 protection mean?
Ans: It provides protection against dust and water splashes in semi-protected environments.
Can it be used outdoors?
Ans: It is suitable for covered or semi-protected installations but not for fully exposed outdoor environments.
Overview
| Door Type | Double Door IP43 |
|---|---|
| No of Ways | 4 |
| Discount Percentage | Between 0-10 % |
| Conformance to standards | IS 8623-1 & 3 IEC 61439-1 & 3 |
| No of Module-Sub-incomer | 4+4+4 |
| No of Module Incomer | 8 |
| Protection against Mechanical Impact | IK 09 |
| No of Module Outgoing | 4+4+4 |
| Height(mm) | 670 |
| Breadth(mm) | 541 |
| Depth(mm) | 122 |
Warranty
- All products listed in the price list are covered by a warranty against manufacturing defects for a period of 18* months from the date of purchase.
- For Lauritz Knudsen MCBs & Isolators mounted inside Lauritz Knudsen Distribution Boards, an extended warranty of 5 years is provided.
- In the event of a defect due to faulty workmanship or other associated reasons, the manufacturer will, at its discretion, remedy the defect or replace the faulty parts or the entire product as soon as possible, free of cost.
- This warranty is subject to proper usage and efficient maintenance and does not cover defects arising from fire, accidents, inefficient maintenance, faulty operation, or deliberate or accidental damage.
- The warranty does not cover damage to power electronic components such as thyristors & IGBTs, which primarily fail due to over-temperature or over-voltage. Users must take adequate precautions to eliminate such conditions.
- The manufacturer shall not be responsible or liable for any special, incidental, social, or consequential losses (including loss of profits), punitive damages, injury, or damages of any kind solely attributable to defect or failure of its products.
- The manufacturer shall not be liable in any manner for issues related to or failure in the performance of any other equipment to which the product is connected.
